The 8827 Chassis Tie Rod Package is the rod that goes through the top and bottom latches. The Tie Rod is held in place by the Special Chassis Nut. The Tie Rod measures 1-3/8" long by 3/16" diameter.
Von Duprin Part # 050328 Old Von Duprin Part # 967616
The Von Duprin 1654-4954 Mullion Brackets 050330 are the top and bottom mullion fittings for the 1654 and 4954 Mullions. . Includes Top and Bottom Fittings, screws and mounting shields.
The 8827 Special Chassis Nut goes on the ends of the 8827 Chassis Tie Rod. The Nut is threaded all the way through so the cover mounting screws can then be threaded on it also. The nut is 3/8" long by 1/4" hex.
Von Duprin Part # 050277 Old Von Duprin Part # 960652
The Von Duprin 900620 35/3348 98/9947 Adjusting Screw Package is used to adjust the concealed vertical rods. This package is used on the 3347, 3547, 3347-F, 3547-F, 9847, 9847-F, 9947 and 9947-F. This is a package of 2.
This Von Duprin Strike 304L Bottom Strike is used for the bottom latch of the 2227, 8827, 9827 and 9927. The strike measures 1-7/8" by 1-7/8" out dimension of the square flange, with an inside dimension of 1-1/8" by 1-1/8". The part that is inserted into the floor is 1-5/16" x 1-5/16" and drops down 13/16". Also known as a Von Duprin Floor Mounted Mortise Strike.
The Von Duprin Old Style Dogging Shaft was used on devices manufactured before July 1997. The Shaft measures roughly 1-1/2" long with a 1/2" diameter. The hex is 5/32".
The Von Dupin 1439 Strike measures 1-7/8 horizontal x 1-3/4 inches vertically. The strike has a projection of 1/2 inch. We find this strike used on the 33A and 35A exit devices.
The Von Duprin 050155 33/99 Cylinder Dogging Conversion Kit converts Hex Dogging Devices to the Cylinder Dogging. For use with the 33A, 35A, 98 and 99 Devices.
The Von Duprin Dogging Adapter 090043 is the piece that the 090042 and 090040 fit through and lock in place. These piece very rarely has to be replaced. The Shaft 090040 is usually the part you need to replace. We sell these individually.
The Von Duprin 8827 050467 Bottom Latch And Cover is the 050461 (latch) and 050464 (cover) in one convenient package. The package includes the cover screws and mount screws.
The Von Duprin 8827 050466 Top Latch And Cover is the 050460 (latch) and 050464 (cover) in one convenient package. The package includes the cover screws and mount screws.
The Von Duprin 22 Center Case 109012 has been around for almost 40 years. This case will replace all of the non fire rated center cases, meaning all of the devices that have a hex key dogging assembly on the hinge side cover plate.
The Von Duprin 2227 Bottom Latch 050090 replaces and updates all 2227 bottom latches to the new style if you device was shipped before October 1998. If your device was shipped after October 1998 then use the G050401.
The Von Duprin Part # 050500 includes the 1 Latch Tail, 2 Latch Tail Rivets, and 2 Latch Tail Springs. This product is used on the Von Duprin 88 Rim Device, for the EO, NL, TP and DT functions. This is not the Latch Tail Kit used on the Fire Rated Von Duprin 88-F Devices.
The Von Duprin 9927 Bottom Latch 050090 replaces and updates all 9827 and 9927 bottom latches to the new style, if your device was installed before October 1998. If your device is newer then October 1998, then use the G050401. Mounting screws and bracket are included.
The Von Duprin 22 Rim Center Case Cover 968603 is for use on the 22 rim devices. The cover comes with mounting screws and is available in aluminum SP-28 or dark brown SP-313.
