Von Duprin 8827 Chassis Tie Rod Pkg 050328

The 8827 Chassis Tie Rod Package is the rod that goes through the top and bottom latches. The Tie Rod is held in place by the Special Chassis Nut. The Tie Rod measures 1-3/8" long by 3/16" diameter.

Von Duprin Part # 050328
Old Von Duprin Part # 967616

Yale 1500 60-1500-1184 Dogging Shaft

Used on the Yale 1500 Rim and Surface Vertical Rod Devices.   This is the peice that the Dogging Key goes in to actuate the Dogging Piece.   The Dogging Shaft measures 1-3/8" long and approximately 5/16" diameter.  The hex is 5/32"

Yale Part # 60-1500-1184

The Von Duprin Tail Piece Guide Lead Kit Package Of 10 - 050156 is used to guide rim cylinder tail piece into the back of the Von Duprin 22, 33A, 98, and 99 exit devices.  We sell these in bags of 10 pieces.

Slot is 5/16" x 3/16" x 1" long
Von Duprin Part # 050156

The Von Duprin Panic Device 230NL Trim is for use with the 22 Rim and 2227 Surface Vertical Road devices.  The key locks and unlocks the panic bar. The plate measures 3" wide by 12-1/16" high and has a plate thickness of 3/32".

The LCN Sentronic Door Closer 4040SE-168 Slider used to be just the slider, the metal part.   In October of 2015 they changed the part so the roller is now included and they are held together by a snap ring or E-clip.

The slider is not longer sold separately, it is sold with the roller.  You have to take the Assembly apart to get just the slider.

The Sargent 624 Bottom Surface Strike is used on the 20, 30, 60, 80 and 90 Series Surface Vertical Rod Panic Hardware.  The Strike is mounted on the floor and the bottom latch locks on to it.   Strike measures 9/16" x 2-1/2" with a 3/8" projection.   Strike features a black coated epoxy.

Sargent Part #624

Fabricated from B & S 16 ga. (.050). Standard lengths are 36", 42" and 48". Custom capabilities include variations of all of the above parts including frame protectors and vertical rod protectors.
Custom sizes are available!

Screws included for mounting

Please allow 7-10 for shipment.

Finishes

3" Kickdown Door Holder / Stop Zinc Plated Mickey

Zinc plated cold rolled steel,
Made in the USA
3" Arm Length

made by Grand Specialties

The Von Duprin 9927 Center Case Cover 050072 replaces your old 1 or 3 piece cover.  The Von Duprin Cover comes with mounting bracket and all screws.

Von Duprin part # 050072

The ESC6600 are non handed, with a Grade 1 thru bolted design. It features a clutch mechanism, double heavy duty spring support to prevent sagging and a hardened stell heavy duty spindle. Entrance function, key locks or unlocks lever, operates as a Classroom Function. Ships with mounting screws and a 6-Pin Schlage Mortise Cylinder.

Jackson Exit Device 2085 Dogging Assembly LH/RHRB

This Jackson Exit Device dogging assembly is used on the 2085 Device made after October 1, 1999. It will work on the previous version of this exit device, but you may have to use a file a remove some material from the catch.

Jackson Part # 30-2462

This spring would be for the Device on the Right, shown below.

The Command Access MLRK1-JAC12 Motorized Latch Retraction Kit With REX is for use on the Jackson CRL 1285 and 1295 Series Exit Devices. The unit is 24 volt with Standard : 900 mA (Avg Current Peak); 200 mA (Avg Current Hold). The unit requires 18 ga wires. The package includes:  1) Motor Mount with MM5; (1) 50944 Molex Pigtail; (1) 50030 6 Feet Lead with VD Connector; (2) 40124 10-24 x 3/8inch Phillips Screws (Silver); (2) 40125 10-24 x 3/8inch Phillips Screws (Black).

The MLRK1-JAC12 is a cost-effective and straightforward way to upgrade your Jackson 12, Kawneer 16/17 and PD16 series device to motor-driven latch retraction in the field. UL Listed + 3 Year Warranty.

The Von Duprin 55 Rim Latch Bolt Spring 967502 is only used on the 55 Rim Panic Hardware.  This spring just keeps pressure on the latch bolt, it does not lift the arm.  If your arm is sagging, they you need to tighten the crossbar wedge tite screws and check and make sure the 55R200 55 Hinge Case Spring is not broken.  It measures 1-1/2" long by 3/8" diameter.

Von Duprin part # 050354
Old Part # 967502

Swivel spindle, 4-3/4" long,
plain centers, 20 tpi

The Dor-o-Matic 1990/2090 "E" Ring RRing.109 is use to connect the concealed rods to the Traveller Assembly (G199028, PB88, or 4270100013).  The rods fit through the traveller and rod bushings, and the Retaining Ring holds them in place.  This piece has a diameter of 1/2".   This item is now under the Falcon name plate.

Dor-o-Matic 990/1990 Repair Parts Breakdown
Dor-o-Matic 1690 Repair Parts Breakdown

Adams Rite 8600 Strike Plate Assembly

The 31-0945 has a 1" outer diameter.

Adams Rite Part # 31-0945

Jackson 2095 Exit Device

Certified ANSI 156.3 Grade 1. Made of extruded aluminum, with stainless steel and hardened steel mechanical components.

Grade 1 Exit Device
Device is non handed
Standard sizes are 30", 36", 42" or 48"
Minimum stile width is 2"

Replacement parts are also available

The Full Mortise Heavy Duty Hinges are standard butt hinge.  They are designed for heavy weight doors with a high frequency of usage.  These are ideal for exterior doors in schools, hospitals and other commercial venues.  The hinge offers four bearings, one between each leaf of the knuckle.  They are constructed of 7 gauge (.180”) steel that is then plated or paint primed.  We sell them in boxes of 3 hinges, and they ship with machine and wood screws.

Shown in brushed chrome

Sargent 60/80 Push Bar Pins-Short Pin

Also known as the push bar axle, this is the pin that you see on the push pad.

1-9/16" LONG

Sargent part # 68-0229

Norton 7700 Series Power Track Arm

Arm is shipped will all of the necessary hardware. This assembly includes the 7701ST-1AT Adjusting Head and Tube Assembly, and the 7701ST-1AR Adjusting Rod Assembly. The square shaft measures 7/16" x 7/16". The aluminum finish ships within 24 hours, dark bronze will take a little longer.

Norton Part # 7701ST-1A

The Sargent Lever Return Spring 97-0425 is usually a green color, however we have seen them in blue and red.  The red spring has the same dimensions as the green, but the loop on the coil side of the spring was closed.  Sargent is using this spring as a replacement for all of those springs.  If you have a Sargent Panic Hardware, and the lever is sagging, or just hanging, this is most likely the problem.  The spring measures 2-1/8" long  by roughly 3/8" diameter.

Sargent part # 97-0425

Adams Rite Old Style Dogging Pin 24-0730

This Adams Rite part is a replacement for worn or stripped dogging pins. The pin has a 1/8" allen head hex.

Adams Rite part # 24-0730

The Door Push Plate 65 is a 16 gauge (.050")  plate made of aluminum, stainless steel, bronze or brass.  The plate offers the antique look, and measures 3" wide by 15" tall.   The package includes matching finish mounting screws.

Finishes

Yale 759 Strike for the 7250 Devices

Used on the Yale 720X Exit Devices.  The Strike measures 2" wide by 3" high and 1/2" thick. Furnished in a Black Finish.

Yale Part # 759

LCN 4310ME-72MC Door Closer Cover

Replacement metal cover for the LCN 4310ME Door Closer

Manufacture Part #:  4310ME-72MC

LCN 4410ME-72MC Door Closer Cover

Replacement metal cover for the LCN 4410ME Door Closer

Manufacture Part #:  4410ME-72MC

DORMA 9300 Series Exit Devices minimize forced entry while offering a low-cost solution to life safety requirements. Certified/listed to ANSI/BHMA 156.3 Grade 1 for exit devices. Package includes all the mounting screws and brackets, and the surface strike.  5 year limited warranty.

The Cal-Royal 221 Bottom Strike is used on the 2000, 5000, 7000 and 9000 Panic Bars with Surface Vertical Rods. Strike measures 2-7/16 inches long with a 5/16 inch projection.  The hole spacing is 1-7/8 inches.

4-3/4" long
9/32" square
16 tpi

The Von Duprin 99 Rim Center Case Cover 050071 replaces your old 1 or 3 piece covers.  Included in the package is the cover and the mounting screws.

Von Duprin part # 050071

Swivel spindle, 4-3/4" long
Two 3/8" solid centers
20 tpi

Swivel, 9/32" square,
16 tpi, 4-3/4" long,
with stop pin

LCN Drop Plate for Pull Side Mounting

Use this LCN Drop Plate when mounting the door closer on the Pull or Hinge Side of the Door. Allows to door closer to me mounted on narrow stile doors.

LCN Part #'s
1260-18
1460-18
4040-18
4040XP-18
4010-18

New for 2024 the Falcon MEL 47867200 Mechanical Latch Retraction. Retrofits all 1690, 1790, 24 and 25 Series devices to Mechanical Latch Retraction. This new system uses the PS902 Power Supply.  The benefits for the MEL Series over the Older EL series are lower power draw (1 amp verse 16 amp), and more flexible power supply location, longer wire runs and thinner guage wires.

Swivel spindle
9/32" square x 4-3/4" long
20 tpi, one 3/8" solid square
