Von Duprin 050046 98/99 Maintenance Kit

In stock
1 Week Lead Time
Part #
G050046
$918.39

The Von Duprin 050046 98/99 Maintenance Kit has all the pieces and screws to keep your 98 or 99 device operating for years.  Kit includes 17 pounds of replacement parts for the panic hardware and the outside trim.

Von Duprin part # 050046

98/99 Maintenance Kit Instruction Manual

Von Duprin 050046 98/99 Maintenance Kit is available to buy in increments of 1

The Von Duprin 050046 98/99 Maintenance Kit has all the pieces and screws to keep your 98 or 99 device operating for years.  Kit includes 17 pounds of replacement parts for the panic hardware and the outside trim.

Von Duprin part # 050046

98/99 Maintenance Kit Instruction Manual

The contents of the kit are as follows:

Quantity

Product name

2

425 SNB PKG-2 US32D

2

325 SNB PKG-2 US32D

4

IMPACT RESIST END CAP BRKT PKG

4

98/9927 ROD GUIDE PKG US32D

2

SA DAMPER ASSY

1

33/35/98/99 E/CAP SCREW PKG

1

VON DUPRIN MAINT. KIT MANUAL

12

264/299F/499F STRIKE SHIM

20

8-32 1/4" UFPH MS STL CZNC

12

10-32 1/4" UFPH MS SS NYL

12

10-24 X 3/4 FPHMS - STL BO

6

WAVE SPRING WASHER SS, .440 ID X .618 OD X .008 THICK, .440

12

10-24 3/4" PPHMS STL CZNC

12

ROLL PIN SPIROL YZNC STL .1/8

24

10-24 1" PPH MS TYP 2A STL YZN

12

#10 EXT TOOTH LOCK WASHER YZNC

12

10-24 X 1 3/8 PPHMS 2A - STEEL

25

TRUARC RET. RING T5304-18 STL

12

10-24 X 3/4 UFPHMS 2A - STEEL

50

8-18 3/8" UFPHMS TYP 25 STL CZ

12

RET RING #5160-42 TRUARC STL

6

1/4-20 5/8" SOC SET STL BO

12

1/4-20 3/4" UFPH MS SS

50

12-14 1/2" HEX WSHR HD TYP AB

20

10-12 X 10-24 X 1 PTHCS - S.S.

10

3347A/9947 RATCHET LEVER SPRIN

10

BOLT RETURN SPRING YZNC

4

CYLINDER RETAINING CUP-210/990

4

ROD EXTENSION CONNECTOR

4

EXT ROD DRILL TEMP.-2227/9927

10

9927 AUX. BOLT SPRING YZNC

12

299 STRIKE SHIM

4

299 STRIKE PLATE

12

NL DRIVE SCREW-99 DEVICE - STL

6

33/99 ANTI-RATTLE SPRING

1

TACKLE BOX

12

3347A/9947 COMPRESSION SPRING

30

TAILPIECE GUIDE

12

992 HEX STUD YZNC

2

HEX DOGGING SHAFT YZNC

2

DOGGING SPRING BO-WAXED

2

DOGGING ADAPTOR SPRING

2

CD ACTUATOR YZNC

24

992 LIFT SPRING

25

SHEAR PIN BD

12

994 HEX STUD YZNC

2

CD DOGGING PLUG YZNC

20

PUSHBAR GUIDE

4

MECHANISM END CAP BRKT YZNC

12

WS SLIC-PIN
