Adams Rite Old Style Dogging Pin 24-0730

This Adams Rite part is a replacement for worn or stripped dogging pins. The pin has a 1/8" allen head hex.

Adams Rite part # 24-0730

Yale 2100 Series Dogging Assembly

yale Part # 60-2100-1001-999

Concealed Top Latch for the ED5800 exit device.  Corbin Russwin part number 650F718.

Dor-o-Matic 1590 HB Cam Assembly

Doromatic part # 4270107285 or PB118

Double Door Latch for doors without a center post. Shown without optional lock. Lock prevents theft.

Dor-o-Matic 1790 NL/HB Cylinder Assembly. Converts a 1790EO to the Night Latch or Hold Back function

Doromatic Part # CYLASY.1151 or 179CA

1790 parts breakdown

Sargent inside/outside spindle

8100 Series rec'g prior to 1/1/1990

includes lever bushings, roll pin and set screws

Sargent part # 578-2, also known as the 81-2946

Jackson Exit Device 1285/1295 Dogging Assembly

Package includes 4 screws, bracket and dogging bracket. Uses 1/8" dog key, our part # 88R6018

Jackson part # 30-2670

Monarch Falcon 060111 Cotter Key Package

Monarch Falcon 060111 Cotter Key Package or 10.  Cotter Key measures 1/8" x 1"

Monarch Falcon Part # 060111
Old Part # 661102

Grade 1 exit device
Device is non handed
Standard widths are 30", 36", 42" or 48"
3-3/4" minimum stile width

Replacement parts are also available

Falcon 603 Concealed Top Latch Kit, used on the 18-C, XX-C, 24-C and 25-C Panic Hardware.

The Corbin Russwin 650F54 is used on the ED4400, ED4800, ED5400 and ED5800 Surface Vertical Rod Devices as the Top Latch Strike. The Strike used to have a roller on it, they no longer have the roller.

The Replacement Rubber Shoe For GJ1153M or Ives FS1153. Constructed of rubber.  Ives part # FSPART.1060

Dorma 8000 Series End Cap comes with the two plastic pieces and the mounting screws.

Corbin Russwin 650F738 Upper Latch used on the ED4800 Narrow Stile Concealed Vertical Rod devices.

No longer available

Doromatic 1590 Cylinder Assembly 159CA-NL

Doromatic part # 159CA-NL

The Dor-o-Matic 1690/1990 Pullman Latch Assembly PB132 is for use with Electric Strikes only.  This part is also some times called the Dor-o-Matic PL Bottom Latch.

Dor-o-Matic Falcon part # 4270101482

Dor-o-matic 1990/2090 Pivot Pin E Ring. This ring is used on the Pivot Pin G199013.

7/16" diameter

Dor-o-Matic 990/1990 Repair Parts Breakdown
Dor-o-Matic 1090/2090 Repair Parts Breakdown

Dor-o-Matic 1790 Center Case Cover.

Replacement Center Case Cover by Falcon Dor-o-Matic is made of die cast metal, then electro-statically painted black.   Cover includes mounting screws.

Doromatic part # COVER.120 or PB329

The Von Duprin 88 Spring Stop Assembly 050451 is the piece that holds the hinge case spring in place. It is used on all of the Von Duprin 88 models.

Von Duprin Part # 050451
Old Part #107682

The Von Duprin 9927 Center Case 050021 center case replaces all earlier versions of the 9827 and 9927 Center Cases. Everything shown in the picture is included with the product. Along with all the mounting screws.

Von Duprin part # 050021

Adams Rite old Style end cap for the 8700 and 8800. Dogging in the head.
The black cap measures 2-3/8" high x 1-5/8" wide x 1-1/4" projection

Adams Rite Part # 41-0801-08

Adams Rite 91-0897-02 RX Monitor Dual Switch is a retrofit kit for all the 3000/8000 exit devices.  The switch has 6 wires to connect to your system.

Adams Rite Part # 91-0897-02

Adams Rite 22-0430-IP 8700/8800 Strike is used on the rim devices that have the Star Wheel Latching System.  The strike measures 2-3/4" long by 1-3/4" wide and projects out approximately 3/8".

The Cal Royal TAIL1 is an extender for the ENTOOL Lever Trim.  The extender works on doors up to 2-1/4 inches thick.  The TAIL1 includes two longer screws, two set screws (not shown), allen wrench, and hub adaptor.

Yale Trim Spring Blue

Also used on Corbin Russwin and Yale Lever trims. The Blue Spring is for RHR or LH doors. The spring has an outside diameter of 1-1/4".

Yale Part # 60-7000-1224-999
Corbin Russwin # 651F62

The Corbin Russwin ED4000/5000 Rim Strike 650F29 is used on the ED4200 and ED5200 Rim Panic Hardware.  A Rim device is an exit device that has the latch bolt protruding from the center case.

Corbin Russwin part # 650F29

The Von Duprin 55 Hinge Case Axle 090051 is used the Rim inactive housing, and all of the other 55 panic hardware.  Such as the 5547, and older 5575's.

Von Duprin Part # 090051 or 090026

Von Duprin 22, 33, 9927 Bottom latch.

Used to replace the bottom latch on the Von Duprin 2227, 3327A, and 9927 on devices shipped after October 1998.

Includes screws and sometimes the bracket

Von Duprin Part # 050401

Doromatic EL1490 Lift Bracket

As known as a Falcon EL1490 Lift Bracket. This bracket connects the exit device to the rods. The bracket measures 7-1/4" long by 1" wide.

Dor-o-Matic Falcon Part # PB57 or 4270107495

Falcon 2130 Bottom Latch Strike

The Falcon 2130 Bottom Latch Strike is used on the 19-V, 24-V, 25-V and XX-V devices.  This strike usually fits into the threshold or is recessed into the floor.

Falcon Part # 2130

Von Duprin 050574 98/9947 Adjustable Top Rod

Von Duprin 98/9947 Adjustable Top Rod for 6'8" to 8'4" doors.  This rod is used on the 9847, 9847-F, 9947 and 9947-F

Von Dupin Part # 050574
Old Part #110375

Swivel spindle
9/32" square x 4-3/4" long
20 tpi, one 3/8" solid square

Dor-o-Matic 1690 Lift Bracket. This is the bracket the Concealed Vertical Rods Connect to.

Doromatic part # BRKT.138 or PB127

Dor-o-Matic 1690 Repair Parts Breakdown

Dor-o-Matic 1490/1590 Dogging Clip

Doromatic part # 971659-79 PB223
