Corbin Russwin ED5400 Panic Device

Corbin Russwin ED5400 Exit Device

Handing
Device is handed but easily field reversible.
Lever trim is handed.
Bar Length
Easily field cut to size.
Standard: 36" (914mm) bar fits 30"- 36" door.
Optional: 24" (610mm) bar fits 24" door; specify W024.
Optional: 48" (1219mm) bar fits 36"-48" door; specify W048.
Door Thickness
1-3/4" (44mm) standard.
Stile
Minimum width 4-1/2" (114mm).
Door Height
Standard top rod for 7' door.
All rods easily field cut to size.
Optional door heights up to 8' available;
Latchbolt
Top: 3/4" (19mm) throw, stainless steel
pullman-type with automatic deadlatching.
Bottom: 5/8" (16mm) throw deadbolt, held
retracted during door swing.
Vertical Rods
1/2" O.D. tubular brass, bronze or stainless
steel with rod guides.

Replacement parts are also available
