Yale Replacement Covers
One of the problems out in industry today is vandalism. These Yale Replacement Covers will replace your existing cracked and broken covers. The covers are available for the 4400, 3300, and 3500 models. They are made of impact resistance plastic. The cover shown is for the 4400, in the aluminum finish.
yale-covers -
Handicap Door Pull 119
With the Handicap Door Pull 119 you are able to get a closed fist behind the pull, which makes it a great ADA Door Pull. Also known as the Double Arm Pull it is constructed of aluminum, brass or stainless steel stock. It measures 8-1/2" overall length and has 5-1/4" centers on the mounting screws. The flat bar stock is 3/8" x 1", and the round mounting post is 3/4" diameter. Shipped with screws and finish washers. Also known as a Handicap Grip, ADA Door Pull or Handle.
GHP300- -
Von Duprin 55NL Cam
The Von Duprin 55NL Cam is one of the handed parts in the housing, the other is the Arm. If you need to change the hand of a housing, you just need to order the other hand Cam.
The Cam shown in the Picture is Right Hand
Von Duprin Part #'s 050355-Right Hand, 050356-Left Hand.
G050355-6 -
Falcon / Doromatic Door Closer 3049/PA Hold Open Arm Only
Doromatic Door Closer Hold Open Arm Only
Doromatic Door Closer Hold Open Arm. Includes everything is the image. Can be used to convert you regular non hold arm to a Hold Open Door Closer. Arm holds the door open when door is rotated open. The hold open postion is adjustable. This is the hold open arm for the SC61 Hw/PA, SC71 Hw/PA, and the SC81 Hw/PA.
Doromatic Part numbers:
SC60 - SC60-3049/PA , SC70 - SC70-3049/PA , SC80 - SC80-3049/PADo-3049 -
ALREX Door Closer Hinge
The ALREX hinge is a full function hydraulic door closer hinge. It contains all the features of a door closer, closing and latching speed control, power adjustment, and optional hold open feature. They are available in 4, 4.5 and 5 inch (leaf height), and are currently available in Stainless and Black finishes.
Package includes 2 hydraulic closer hinges and one dummy, for a standard 3 x 7 foot door, 100 pound door.
Door Handing:
AX21 -
Von Duprin Panic Device 99 Lever Trim
The Von Duprin Panic Device 996L Lever Trim has an escutcheon plate that measures 2-3/4" wide by 10-3/4" high and projects out 27/32". The handle projection is 2-7/8". The key cylinder, not included, locks and unlocks the lever. This lever handle is handed, but is field reversible. Key lock and unlocks lever. We ship the 996L-R&V
99L -
Door Pull 25 3/4" Diameter
The Door Pull 25 is made of 3/4" round stock in either solid, Aluminum, Brass or Stainless Steel. The handle has a 2-3/8" projection from the door, and 1-5/8" clearance from the door to the back of the handle. It comes standard with thru bolts and finish washers, but can be special ordered if you would like the handle mounted back to back or surface mounted. Also known as a Door Handle or Door Grip.
GHE25 -
Von Duprin 050500 88 Latch Tail Kit
Von Duprin 050500 88 Latch Tail Kit
The Von Duprin Part # 050500 includes the 1 Latch Tail, 2 Latch Tail Rivets, and 2 Latch Tail Springs. This product is used on the Von Duprin 88 Rim Device, for the EO, NL, TP and DT functions. This is not the Latch Tail Kit used on the Fire Rated Von Duprin 88-F Devices.
Von Duprin Part # 050500
G050500 -
Finger Protector For Doors - Exterior Pull Side
Door Finger Protector - Exterior Pull Side
This model is specifically designed for exterior doors on the pull side of the door. This patented Finger-Gard product is designed for both exterior and interior doors and thus will operator in very cold and very hot tempetures. Flexible to minus 40 degrees. They are made of a special rubber that is resistant to harsh sunlight. They will allow the door to swing up to 180 degrees. This product is available in Brown or White, 78" or 83" lenghts
Our part # on this is GFG7 for the 78" length, and GFG7+ for the 83" length.
GFG-D -
Floor Door Stop / Holder FS446
Floor Door Stop / Holder FS446
The Ives FS446 Door Stop and Holder is a modification of the FS444, which is the non holder version. It is considered a manual type floor holder, because you have to manually latch the holder for it to hold the door open. It is constructed of cast bronze or brass, and is no longer available in a cast aluminum. It is designed for doors with up to 2-1/2" of undercut, meaning the distance between the finished floor and the bottom of the door. It measures 3-3/4" overall height with a 2-1/2" diameter, and the distance from the base to the center line of the rubber non-marring stop is 2-1/2". This stop is packed with expansion shield and lead shield.
GJF26- -
Ives FB61P Constant Latching Flush Bolt for Wood Doors
Ives FB61P Constant Latching Flush Bolt for Wood Doors
The Ives FB61P is used on the inactive leaf of wood fire doors. The latch remains extend until the active door is opened. When the active door is opened the latches retract, and extend when the active door is closed. The bodies measure 1” wide by 8-1/2” tall and 2” deep. The bolt throw is 3/4” with a 7/8” vertical adjustment, and has a 3/4” backset. This package comes with the top and bottom flush bolts with screws and strikes.
90 minute UL Rated.
Ives Part # FB61P
FB61P- -
Door Pull Handle 24
The Door Pull Handle 24 features a 6" center to center screw spacing. The handle is constructed of aluminum, stainless steel or brass depending on the desired finish. The handle is 1" solid diameter stock and the mounting posts are 3/4" diameter stock. It measures 8" overall length and projects from the door 2". It ships with thru bolts and finish washers. Also known as a Door Handle or Door Grip.
GHE24- -
Yale Door Closer 51 Series
The Yale Door Closer 51 Series has been around since the early 1970's. With the advent of the aluminum framed storefront doors, this door closer was a perfect fit. The 50 series is a non-sized, non-handed closer that can be mounted on the push (parallel arm), pull (regular arm) or top jamb. A Grade 1 closer certification, means it is one of the more heavy duty closers out there. Older models may be stamped with Scoville or Eaton, which are the companies that used to own Yale. We some times find 20-0054-4001 or 20-0254-4001 stamped on the back of the closer. Ships with all mounting screws and a parallel arm bracket. The hole spacing is 3/4" by 9-1/16".
50- -
Detex EAX-300W Weatherized Battery Powered Door Prop Alarm
Detex EAX-300W Weatherized Battery Powered Door Prop Alarm
The Detex EAX-300W Series is designed for applications where doors may be used for egress or ingress, but may not be held or propped open. Door open times from 1 second to 4 minutes (15 second default) are field selectable. The smaller size makes installation quick and easy. The Weatherized version is designed for doors that open to the outdoors or environments.
Cylinder not included!
Uses a standard 9 volt batteryEAX300W- -
Door Pull Offset 3/4" Diameter 29
The Door Pull Offset 3/4" Diameter #29 is constructed of either solid, Aluminum, Brass or Stainless Steel. The handle 3/4" diameter tubing with a 2-1/2" projection and 2-1/2" offset. We find these on narrow stile aluminum framed glass storefront doors. It comes standard with thru bolts and finish washers, but can be special ordered if you would like the handle mounted back to back or surface mounted. Also known as a Door Handle or Door Grip.
GHE29 -
Finger Protector For Doors - Interior Pull Side
Door Finger Protector - Interior Pull Side
These patented door guards fold against the jamb, allowing them to swing completely 180 degrees. The guard is attached to the face of the door and frame with the provided strong adhesive tape. Clear-frosted color to compliment any color scheme. Finger-Gard for use on Interior Doors, on the pull side. Available in 54" or 78" lengths.
Part number GFG3 for 54" length, and GFG4 for the 78" length
GFG-B
