Ives 7212INT Intermediate Pivot
• Use with 7212, 7212V or 7222 3/4 Offset Pivot
• Handed
• Vertical adjustment 3/16", include positive locking.7212INT -
LCN 4040 Super Smoothee Door Closer
Standard 4040 LCN series closer shipped with regular arm, standard plastic cover, and self reaming and tapping screws. Non-sized cylinder is adjustable for interior doors to 5’0” and exterior doors to 4’0”. Closer mounts hinge side, top jamb, and parallel arm w/PA Shoe on either right or left swinging doors. Closers to meet ADA requirements.
No longer made, the 4040XP will be shipped in its place.
4040- -
Door Pull Handle 16
The Door Pull Handle 16 has an overall length of 7-1/2". The base diameters are 2" with three holes each. The handle projects out 2-1/4" and has a clearance of 1-1/2". Also known as a Door Grip or Door Handle. This handle ships with 6 wood/sheet metal screws.
GHE16- -
Sargent 8700 Panic Device
For Doors Wood or metal. 1-3/4" (44 mm) thick standard.
minimum stile with trim and 3-1/2"
Mounting Supplied standard with wood and machine screws
Chassis Cover Cold drawn brass, bronze or stainless steel
Chassis Nonferrous alloy
Hand Handed. Specify RHRB or LHRB
Dogging Feature Allen-type dogging furnished standard.
Top and Bottom Bolts Brass, stainless steel8700EO -
Von Duprin Panic Device 880K Trim
The Von Duprin Panic Device 880K Trim is for use with the 88 series devices only. Plate measures 3" wide by 14-3/16" long with an 1-5/8" diameter bore for cylinder. Knob projects out 2-3/4". We do not sell many of these anymore, due to ADA requirements, but they are still available.
88K- -
Von Duprin Panic Device 99 Lever Trim
The Von Duprin Panic Device 996L Lever Trim has an escutcheon plate that measures 2-3/4" wide by 10-3/4" high and projects out 27/32". The handle projection is 2-7/8". The key cylinder, not included, locks and unlocks the lever. This lever handle is handed, but is field reversible. Key lock and unlocks lever. We ship the 996L-R&V
99L -
Von Duprin Strike 264
The Von Duprin Strike 264 measures 2-7/8" tall by 1-1/4" wide with a roller projection of 9/16". Used on the Von Duprin 22, 88, 98 and 99 when a lower profile strike is need in place of the Von Duprin 299 Strike. The hole spacing is 2-1/8" on center, and it ships with mounting screws and a shim. Also known as a Von Duprin Surface Roller Strike.
Von Duprin Part # 264
264 -
Dor-o-Matic Panic Device 2090 / 1790 Standard Strike
The Falcon / Dor-o-Matic Panic Device 2090 / 1790 Standard Strike is the strike shipped with all new Falcon 2090 and 1790 exit devices. The strike measures 1-3/4" high, 1-3/4" deep and only comes in a Black Matte color. This strike was known for a long time as the Dor-o-Matic SD36 Strike, but after changing there name to Falcon in about 2008, it is know known as the Falcon SD36 Strike.
G2090STK -
Von Duprin 55 Rim Latch Bolt Spring 967502
The Von Duprin 55 Rim Latch Bolt Spring 967502 is only used on the 55 Rim Panic Hardware. This spring just keeps pressure on the latch bolt, it does not lift the arm. If your arm is sagging, they you need to tighten the crossbar wedge tite screws and check and make sure the 55R200 55 Hinge Case Spring is not broken. It measures 1-1/2" long by 3/8" diameter.
Von Duprin part # 050354
Old Part # 96750255R210 -
Floor Mounted Dome Stop FS439
The Ives Universal Dome Floor Stop FS439 is constructed of cast zinc or stainless steel, depending on the finish. The stop measures 1-1/2" high, with a base height of 1/4" and base diameter of 1-7/8". The pad has a height of 1-1/8" from the floor.
Ives Part Number FS439
GFS439- -
Von Duprin Dogging Hook 090044
The Von Duprin Dogging Hook 090044 is the piece that grabs the push bar mechanism and keeps it in the dogged position. The does wear out, but it takes a long time. This piece is used on the 22, 33A, 35A, 98 and 99 series devices made after 1997. We sell this part individually and it is #5 on the diagram.
G090044
