Von Duprin EL99 Panic Device Only
This is the same trusted Von Duprin 99 with Electric Latch Retraction, also known as EL.
The EL feature allows for the remote unlatching of exit devices. A control station operator can flip a switch to retract the latch bolt and immediately change an exit door to push-pull operation. A powerful, continuous duty solenoid retracts the latch bolt, either for momentary unlatching, or for extended periods of time. The EL feature is an alternative to manual dogging.
EL devices are also useful with automatic door operators, and may be applied to fire-rated applications when under the control of an automatic fire alarm system.
UL approved for Class II circuit applications.
The EL option does not include the power transfer from door to frame, the power supply, or the control operator. Refer to EPT-2 power transfer and the PS914 power supply.
The PS914 with the 9002RS option card is the minimum option card required. Other option cards available for other functions, see PS914 power supply for additional information.
Ships with all the mounting screws and the 299 Strike.
EL99EO-Von Duprin Strike 264
The Von Duprin Strike 264 measures 2-7/8" tall by 1-1/4" wide with a roller projection of 9/16". Used on the Von Duprin 22, 88, 98 and 99 when a lower profile strike is need in place of the Von Duprin 299 Strike. The hole spacing is 2-1/8" on center, and it ships with mounting screws and a shim. Also known as a Von Duprin Surface Roller Strike.
Von Duprin Part # 264
264Von Duprin 100316 5547 Top Plate
The Von Duprin 100316 is used on the 5547 on the top of the door. The top rod goes through the square hole on the plate. The plate shown in the Picture has both sides or LHR and RHR doors. One side of the strike is usually broken off depending on the hand of the door.
G100316Von Duprin 050611 Lever Trim Shear Pin | Von Duprin Panic Hardware
Von Duprin Exit Device Lever Trim Shear Pin Kit
This is the component that is designed to break, if the lever handle is forced to open , this pin snaps so your trim is not destroyed. 3/16" diameter shaft by 5/8" overall length. Retaining Ring included. This shear pin is used on the 230L, 360L, 992L, 994L and 996L Von Duprin Lever Trims.
Von Duprin Part # 050611 Old Part # 971583
G050611Von Duprin 9927 Bottom Vertical Rod 110574
The Von Duprin 9927 Bottom Vertical Rod 110574 is the replacement rod for broken or bent vertical rods. All of the 9927 bottom rods are the same length, this is set by Federal Building Codes, so the center line of the Panic Hardware is a certain height from the finished floor. The length of the rod is 31-1/4" long, less the fittings. The old part number on this was 110574, and the newer one is 050514.
G99VR50-Von Duprin 88 Lever Arm Right Hand 050438
The Von Duprin 88 Lever Arm Right Hand 050438 replacement lever arm for all the Von Duprin 88 exit devices. Usually replaced due to the dogging screw stripping out. The arm includes the Wedge, Wedge Ring, Wedge Tite Screw and Dog Screw, and sometimes the axle.
Von Dupin part # 050439
Old Part # 10072988R80-Door Pull Handle 11
The Door Pull Handle 11 has 8" center to center screw spacing. The base is 3/4" diameter, the overall lenght is 9-1/4". The projection is 2-1/8" and the clearance is 1-1/2". Also known as a 8" Center Door Grip or Door Handle. This handle is shipped with thru bolts and finish washers.
GHE11-International Door Closer 5510S Rim Device
International 5510S Rim Device-Light Duty
All devices are non-handed design
Auxiliary guarded latch deadlocks latch bolt automtically locks when the door is closed
High shock-resistant latching mechanical design or protection from vandalism
All inside components are made of high rust-resistant alloy or heavy electroplated steelStandard 36”: Device length is 33 15/32” (850mm) for 3’ door use, with a standard push bar.
Long 48”: Device length is 44 3/4” (1137mm) for 4’ door use, with long push bar.5510S-Back to Back Offset Door Pull 1.25 inch
Back to Back mounted Off-Set Door Pull featuring 1-1/4 inch stock diameter stock. Handle has a 4 inch offset with a 2 inch clearance and 3 1/4" projection. Available in 12 or 18 inch centers. Sold as sets, 2 handles and 3/8-24 thread stud.
Back to Back fasteners are for a 1-3/4 inch thick door, if your door is a different thickness, please let us know in the comments.
Aluminum and Stainless Steel ship in 1 week, all other finishes ship in 2 weeks. Made in the USA.
GHEM39xM39Von Duprin 55NL Cam
The Von Duprin 55NL Cam is one of the handed parts in the housing, the other is the Arm. If you need to change the hand of a housing, you just need to order the other hand Cam.
The Cam shown in the Picture is Right Hand
Von Duprin Part #'s 050355-Right Hand, 050356-Left Hand.
G050355-6Von Duprin Panic Device 99 Lever Trim
The Von Duprin Panic Device 996L Lever Trim has an escutcheon plate that measures 2-3/4" wide by 10-3/4" high and projects out 27/32". The handle projection is 2-7/8". The key cylinder, not included, locks and unlocks the lever. This lever handle is handed, but is field reversible. Key lock and unlocks lever. We ship the 996L-R&V
99L4" Kickdown Door Holder FS452
4" Kickdown Door Holder FS452
The H.B. Ives FS452 is another classic kick down door stop. It features a simple hold and release, activated with a touch of the foot, and is constructed of cast bronze or brass depending on the finish you are ordering. A simple stainless steel spring clip holds the stop in the up position. The non-marring rubber shoe is replaceable, and they have a corrugated bottom to prevent sliding on the floor and a secure grip. This stop is shipped with matching finish sheet metal screws. The 4" model is for door to floor clearances of 2" or less. The hole spacing is 19/32" x 1-47/64".
Ives Part # FS452
GJ452-4-LCN Door Closer 4111 FL
The LCN Door Closer 4111 FL is known as the Smoothee, and is one of the heaviest duty door closers made, the FL stands for Fusible Link. The Fusible Link is a lead clip that melts at roughly 115 degrees, and releases the door so it can close and contain a fire. If you have a building were you have a high traffic and abusive, especially exterior doors, then this is the closer. The 4111 is an application specific closer, meaning it will only work when mounted on the door, on the push side. This is known as a parallel arm application. The cylinder is fully adjustable and will work on doors up to 56" exterior door, and can be adjust down to ADA required levels. We ship the 4111 FL model, which is a hold open fusible lind, on this page. The cylinder mounting holes are 2-1/2" by 6".
4110FLLCN Door Closer 4111 HEDA Hold Open
The LCN Door Closer 4111 HEDA Hold Open is known as the Smoothee, and is one of the heaviest duty door closers made, the HEDA stands for Hold Open Extra Duty Arm. If you have a building were you have a high traffic and abusive, especially exterior doors, then this is the closer. The 4111 is an application specific closer, meaning it will only work when mounted on the door, on the push side. This is known as a parallel arm application. The cylinder is fully adjustable and will work on doors up to 56" exterior door, and can be adjust down to ADA required levels. We ship the 4111 HEDA model, which is a hold open arm on this page. The cylinder mounting holes are 2-1/2" by 6".
4110H-LCN Door Closer 4111
The LCN Door Closer 4111 is known as the Smoothee, and is one of the heaviest duty door closers made. If you have a building were you have a high traffic and abusive, especially exterior doors, then this is the closer. The 4111 is an application specific closer, meaning it will only work when mounted on the door, on the push side. This is known as a parallel arm application. The cylinder is fully adjustable and will work on doors up to 56" exterior door, and can be adjust down to ADA required levels. We ship the 4111 EDA model, which is a non hold open arm, on this page. The cylinder mounting holes are 2-1/2" by 6".
4110Yale Door Closer 3501
The Yale Door Closer 3501 is constructed of a cast aluminum alloy. It is considered a Grade 1 Closer, which is the highest grade possible. The closer features an adjustable spring tension, and separate closing, latching and back check intensity valves. The full plastic cover is standard on this closer. This door closer replaces the older 3501BF closers. The new version is Barrier Free Complaint. The hole spacing is 3/4" x 12", the cylinder is sometimes cast 20-3301-1001 on the back of the cast aluminum cylinder. This closer ships with all of the mounting hardware and parallel arm bracket.
3500-Von Duprin 9927 Bottom Latch 050090
The Von Duprin 9927 Bottom Latch 050090 replaces and updates all 9827 and 9927 bottom latches to the new style, if your device was installed before October 1998. If your device is newer then October 1998, then use the G050401. Mounting screws and bracket are included.
Von Duprin Part # 050090
G99VR55Von Duprin Panic Device 7500 Mortise Body Only
This Von Duprin Panic Device 7500 Mortise Body Only is used on the Von Durprin 8875, and Von Duprin 98-9975 panic hardware. The body measures 5-7/8" high by 4-1/2" deep and 1" thick. This is the body that has been used since about 1977.
Call or email for pricing on the SS7500, 7500-IN, and E7500 Mortise Bodies and replacement parts for the Lock.
We ship the 7500 in US32D, brushed stainless steel.
G7500Rixson Checkmate Overhead Door Holder 9 Series
Rixson Checkmate Overhead Door Holder 9 Series
Product Description & Features
• Doors are single acting
• Non-handed
• Slide track design
• Recommended for high traffic, heavy
abuse installations
• Heavy shock absorber spring provides
5-7° compression before deadstopSize is the Door Width
GR09Finger Protector For Doors - Exterior Push Side
Door Finger Protector - Exterior Push Side
This model is specifically designed for exterior doors on the push side of the door. This patented Finger-Gard product is designed for both exterior and interior doors and thus will operator in very cold and very hot tempetures. Flexible to minus 40 degrees. They are made of a special rubber that is resistant to harsh sunlight. They will allow the door to swing up to 180 degrees. This product is available in Brown or White, 78" or 83" lenghts
Our part # on this is GFG5 for the 78" length, and GFG5+ for the 83" length.
GFG-C
