The Jackson Panic Device 1095 Standard Strike is a strike they have been using for the past 20 years.  You might have one of the older roller strikes, but this will work in its place.  The older style roller strike is no longer available.  Jackson Exit Device part # 30-2436.

The Jackson Panic Device Top Bolt Trip is for use on the 1085, 1285, and 2086 devices.  The 30-824 Trip Assembly mounts on the jamb stop and has a pin that sticks out of it (actually a threaded set screw).  The pin lines up with the release plate on the Top Bolt Guide Assembly, when the pin hits the top plate as the door closes, it releases the rods, so they can extend.

The Jackson Panic Device 1085 and 1095 Thumb Piece Dogging Pin 30-1117 is a replacement for the Screw Driver Headed Dogging Pin.  Now instead of using a screw driver you can use the handy thumb piece instead.   The package comes with new set screw, spring, and of course the pin.  Jackson part number 30-1117.

The Jackson 1085 30-1242 / 30-1243 Lever Arms are for use with the Jackson 1085 Housings, both sides.  And the Jackson 1095 Inactive (hinge side) Housings.  To determine hand, stand inside and look out the door, what is side is the arm on?  If it is on the Right then order Right.

The Jackson 1095 30-1247 / 30-1248 Lever Arm.  Replacement Lever Arm for the Jackson 1095 Active Housings.   This arm will only work on the 1095 Active Case!  The difference between this arm and the 1085 arm is the Pin in in the top of the arm.   The pin fits into the triangular linkage clip, which actuates the latch bolt.  Handing is determined by standing inside and looking out, if the arm in on the right hand side of the door, it is a right hand lever that you would order.

The Jackson 1095P Paddle Panic Hardware is an alternative to the cross bar or push pad style panic hardware.  The device is the same as the Jackson 1095, but with a paddle instead of the cross bar.   This device is for use on aluminum or steel doors only.   The device is mounted on surface studs that are tapped into the door.  On a wood door they will pull out.

Right Hand Reverse Shown

Jackson 1095 Gear Package

Jackson part # 30-852

Jackson 1095 RH Backplate Assembly

Jackson Part # 30-846

Jackson 1095 LH Backplate Assembly

Jackson Part # 30-847

Jackson Panic Device 1295 Push Pad End Cap Package

Package includes two end caps, one bracket mounting screw, and 4 end mounting screws. This product was just upgraded to a metal cover, which will replace the old plastic cover.

Old Jackson part # 30-2677
New Jackson Part # 30-2654

Jackson Panic Device 1285 Push Pad End Cap Package

Package includes two end caps, one bracket mounting screw, and 4 end mounting screws. This product was just upgraded to a metal cover, which will replace the old plastic cover.

Old Jackson part # 30-2661
New Jackson Part # 30-2652-628 or 30-2652-313

Jackson 30-2674 1285/1295 Cover Package

Jackson part # 30-2674-313 and 30-2674-628 Cover Plate for use on the 1285 and 1295 devices..  Plates measure 2-11/16" x 7-1/2 and 2-11/16" x 2-1/8", two plates in each package.

Jackson Part #'s 30-2674-313 and 30-2674-612

The Jackson 1285/1295 Push Bar End Cap Package comes complete with the right and left side caps, mounting bracket and screws.  This piece is available in aluminum (silver) and dark bronze (dark brown).

Jackson Part # 30-2650

Jackson Exit Device 2085 Dogging Assembly LH/RHRB

This Jackson Exit Device dogging assembly is used on the 2085 Device made after October 1, 1999. It will work on the previous version of this exit device, but you may have to use a file a remove some material from the catch.

Jackson Part # 30-2462

This spring would be for the Device on the Right, shown below.

Jackson Exit Device 2085 Dogging Assembly RH/LHRB

This Jackson Exit Device dogging assembly is used on the 2085 Device made after October 1, 1999. It will work on the previous version of this exit device, but you may have to use a file a remove some material from the catch.

Jackson Part # 30-2467

This spring would be for the Device on the Left, shown below.

Jackson Exit Device 2085/2095 End Cap

The Jackson Exit Device 2085/2095 End Cap measures 3-1/8" high, by 1-1/8" wide, and has a projection of 1-15/16". The mounting lugs are 1-3/8" on center and project out 1".

Jackson Part Number 30-1266-628 Aluminum
Jackson Part Number 30-1266-313 Dark Bronze

The Jackson 30-1345 Top Strike Package for the 2085-3185  is mounted on the frame of the door were the top latch can engage it.   The Package includes the Strike, Plate, Latch Adjusting Wrench and the Mounting Screws.   Jackson Part Number 30-1345.

The Jackson 30-1345 Top Strike Package for the 2085-3185  is mounted on the frame of the door were the top latch can engage it.   The Package includes the Strike, Plate, Latch Adjusting Wrench and the Mounting Screws.   Jackson Part Number 30-1345.

Jackson Exit Device replacement 1295 Latch Assembly.

Jackson Part # 302679

The Sargent 646 Surface Strike is used on the 20, 30 and 80 Series Surface Vertical Rod Panic Hardware and Fire Rated Hardware.  It is used as a strike for the top latch. The strike measures 1-5/32" x 3-11/16"  with a 3/4" projection.   Strike features a black coated epoxy finish.

Sargent Part #646

The Sargent 649 Surface Strike is used on the 20, 30, 60 and 90 Series Rim Panic Hardware.  The Strike measures 1-5/32" x 3-11/16"  with a 3/4" projection.   Strike features a black coated epoxy finish.

Sargent Part #649

The Sargent 624 Bottom Surface Strike is used on the 20, 30, 60, 80 and 90 Series Surface Vertical Rod Panic Hardware.  The Strike is mounted on the floor and the bottom latch locks on to it.   Strike measures 9/16" x 2-1/2" with a 3/8" projection.   Strike features a black coated epoxy.

Sargent Part #624

The Sargent 655 Bottom Surface Strike is for use the 20, 30, 80 and 90 Series Surface Vertical Rod Panic Hardware.  The Strike measures 1-13/16" x 2-3/4" x 3/32" thick.

Sargent Part #655

The Sargent Lever Return Spring 97-0425 is usually a green color, however we have seen them in blue and red.  The red spring has the same dimensions as the green, but the loop on the coil side of the spring was closed.  Sargent is using this spring as a replacement for all of those springs.  If you have a Sargent Panic Hardware, and the lever is sagging, or just hanging, this is most likely the problem.  The spring measures 2-1/8" long  by roughly 3/8" diameter.

Sargent part # 97-0425

Sargent Exit Device Et Spindle Adapter

7/16" diameter x 1-1/2"
input square shaft is 5/16"

Sargent 700 ET Spindle Kit 730-7

This Sargent Kit 730-7 includes the spring, spindle and the associated plates. Look under "More Views" for a detailed look of this repair kit. The 730-7 is for 1-3/4" doors.   Shank measures 4-1/4" long, square spindle is 5/16" square.

Sargent Part # 730-7

Sargent 97-0050 Knob Return Spring

This Sargent Knob Return Spring measures 1-1/16" overall length by 3/16" diameter

Sargent Part # 97-0050

Sargent 97-2434 Old Style 8700 Top Latch

The Sargent 97-2434 Old Style Top Latch was used on the 8706, 8710, 8713, 8715, 8728, 8740, 8743, 8746,  8762, 8763, 8773, and 8774 Series Surface Vertical Rod Devices before November 11, 2002.  We sometimes fine the casting number of 97-0317 stamped on the back of this latch.  This Top Chassis has 3 mounting holes.

Sargent Part # 97-2434

Sargent 700 ET Spindle Kit 730-7

This Sargent Kit 730-7 includes the spring, spindle and the associated plates. Look under "More Views" for a detailed look of this repair kit. The 730-7 is for 1-3/4" doors.   Shank measures 4-1/4" long, square spindle is 5/16" square.

Sargent Part # 730-7

The Sargent 20/60 Plastic End Cap Only 68-0434 will also work on the 30 Series Panic Hardware.   The cap has been manufactured for the last 40 years and is made of high impact plastic.  The end cap measures 1-5/8" wide by 2-3/8" tall and projects out 2-3/4".

Sargent Part # 68-0434

The Sargent Exit Device 20/30/60 End Cap And Bracket is a part we put together here for your convenience.  Sargent only sells these components separately.  Usually only the cap goes missing, but every once and while the bracket goes missing also.  The package is used on the all of the 20, 30 and obsolete 60 series devices.

Sargent Part # 68-0434, 68-2141, and 97-0052

The Sargent 20/30/60  End Cap Bracket is used with the larger end cap.  This end cap has been manufactured for the last 40 years and started its life on the obsolete 60 Series.  The bracket holds the hinge side of the exit device on the door, and the G20300C fits over the top of it.

Sargent part #68-2141

The Sargent 20/30/60/80 Connecting Arm Spring is the spring that pushes the touch pad back out after you push it in.   It is used on the 20, 30, 60 and 80 Series Panic Hardware.

Sargent part # 68-0236

Sargent Latch Bolt Spring.

Used to put tension on the latch bolt of the 20, 30, 60, and 80 Series Sargent exit devices

Sargent Part # 98-0028

The Sargent 20/30/60/80 Dogging Kit 68-2596 is used on the Sargent 20, Sargent 30, Sargent 60, and Sargent 80 Series Panic Hardware. This dogging assembly kit has been around since the 1980's.  We only sell the dogging assembly parts as a complete set.

Sargent part # 68-2596

Sargent Exit Device 80 Series Plastic End Cap

This part is the weak link in this exit device. When the end cap falls off the Dogging Cover Plate falls out also! The end cap is 1-1/8" wide by 2-7/16" tall and projects out 1-7/8".

Sargent Part # 68-0561
